Controls and Instruments
66
INTAKE AIR PREHEATER ON – WAIT BEFORE STARTING
06740_E
Illuminates when the intake air preheater element is in function. Wait until this telltale
light has turned off before starting the engine. For more information on this feature, refer
to paragraph “Cold Weather Starting” in Starting And Stopping Procedures chapter.
FLAT TIRE (WITH OPTIONAL TIRE PRESSURE MONITORING SYSTEM)
06740_F
Illuminates when a tire pressure is 25% below the target tire pressure.
HILL START ASSIST
06740_G
Indicates a malfunction of the hill start assist function. This function might not be
available.
ANTILOCK BRAKE SYSTEM (ABS)
06740_H
Illuminates when the ABS is not available or when the ABS is malfunctioning. Since the
ABS system does not operate at less than 4 mph (7 km/h), the indicator will remain
illuminated until the coach reaches that speed. Refer to Other Features chapter.
TRAILER ANTILOCK BRAKE SYSTEM (ABS)
06740_I
Illuminates when the trailer ABS is not available or when the trailer ABS is
malfunctioning.
TCS/ESC - TRACTION CONTROL SYSTEM AND ELECTRONIC STABILITY
CONTROL
06740_AA
This telltale illuminates and stays on whenever TCS or ESC is disabled due to a
diagnostic fault code.
During an ESC or TCS intervention, the telltale will blink rapidly to indicate this action.
When in TCS mud/snow mode, this telltale will blink continuously to indicate that this
mode is active. When the TCS mud/snow is active, the ESC is disabled at speed lower
than 25 mph (40 km/h), for this reason, the telltale will stop blinking and will stay on.
HIGH BEAM
06740_K
Illuminates when the high beams are selected. High and low beams are selected with
the multi-function lever. Refer to “Steering Column Controls” paragraph in this chapter.
