Components Identification
The numbers indicate the name of the specific component. Read the paragraphs below for detailed operation description.
page 4
Power IN 12V
HDMI port for external monitor
3
4
n.2 USB 3.0 ports
5
n.2 USB 3.0 ports
7
On / Off switch
8
n.4 12V power OUT
2
Network port
n.4 USB 2.0 ports
WiFi Antenna
1
6
n.3 power out ports with regulated voltage
9
10
EYE light sensor
11
Status LEDs
GPS Antenna
12
13
