Prime Controls DS600 - Discrete Coil Outputs (000001); Discrete Coil Inputs (100001)

DS600 Non-Ferrous Double Sheet Detector
This document is confidential and proprietary. No part of this document may be disclosed in any manner
to a third party without the prior written consent of Prime Controls, Inc.
202177 19 Revision M
4.2.1 Discrete Coil Outputs (000001)
Coil
Address
Name
Meaning
000001
Left Green LED
Left Green LED (Accept LED)
000002
Left Red LED
Left Red LED (Accept LED)
000003
Right Green LED
Right Green LED (Reject LED)
000004
Right Red LED
Right Red LED (Reject LED)
000005
Net Green LED
Network Green LED
000006
Net Red LED
Network Red LED
000007
Accept
Accept Output
000008
Reject
Reject Output
000009
Fault
Fault Output
000010
AuxOut
Auxiliary Output
000011
NetCalReg
Calibration request
000012
NetHighReq
Force outputs high
000013
NetLoReq
Force outputs low
4.2.2 Discrete Coil Inputs (100001)
Coil
Address
Name
Meaning
100001
DIPSw1
DIP Switch 1 Input
100002
DIPSw2
DIP Switch 2 Input
100003
DIPSw3
DIP Switch 3 Input
100004
DIPSw4
DIP Switch 4 Input
100005
DIPSw5
DIP Switch 5 Input
100006
DIPSw6
DIP Switch 6 Input
100007
DIPSw7
DIP Switch 7 Input
100008
DIPSw8
DIP Switch 8 Input
100009
InputReg 1
Calibrate pushbutton
100010
InputReg 2
External Calibration Input
100011
InputReg 3
Reset input
100012
MemSelReg0
Mem Sel 0 input
100013
MemSelReg1
Mem Sel 1 input
