5 TROUBLESHOOTING
Should trouble develop, proceed as follows:
1. Check +24V input power to the controller.
2. Verify the integrity of all electrical connections to the unit.
3. If the unit powers up, initializes and the indicators show a response to changes in metal
at the probe face but the outputs are not changing, check that the RESET input is set to
unlatch and that the IN REF input is properly wired for the type of RESET input. If the
RESET input is not used, connect it to common if IN REF is connected to +24V or
connect it to +24V if IN REF is connected to common.
4. On the DS600PC the ModBus ID must be configured to enable Modbus communication.
5. Use the diagnostic messages displayed and Table 10 to identify an appropriate
corrective action
For further information on service assistance, contact Prime Controls, Inc., 4528 Gateway
Circle, Dayton, Ohio, 45440 USA. Phone +1(937)435-8659. Have the model number and serial
number of the unit available to expedite service.
Table 10 - Messages – All Models
Message
Full Name
Meaning
Power On Messages
dS 600
Model DS600
System Identification as DS 600
dS 600P
Model DS600P
System Identification as DS 600P
dS 600PC
Model DS600PC
System Identification as DS 600PC
Prb #
Probe #
Probe identification value
SEL #
Select #
Memory Selection value
Parameter Value Messages
SEL
Select
Memory selection input parameter
Htol
High Tolerance
High Tolerance input parameter
Ltol
Low Tolerance
Low Tolerance input parameter
Udly
Under delay
On-delay to reporting an under condition
tol
Tolerance
Part Present Tolerance input parameter
Id
Identification
ModBus Identification value (address)
