Prime Controls DS600 - Holding Registers (400001)

DS600 Non-Ferrous Double Sheet Detector
This document is confidential and proprietary. No part of this document may be disclosed in any manner
to a third party without the prior written consent of Prime Controls, Inc.
202177 21 Revision M
4.2.4 Holding Registers (400001)
Register
Address
Name
Size
Meaning
400001*
Consolidated coils
Word
Copy of bits 000001 through 000013
400002*
Consolidated discr ins
Word
Copy of bits 100001 through 100015
400003*
System variant code
Byte
Copy of 300001
400004*
Network ID
Byte
Copy of 300002
400005*
Display Mode (0, 1, or 2)
Byte
0 => 4 digits, 1 => alternating, 2 => scroll
400006*
Display Text
6 Words
Currently displayed text
400012*
Display average (0-100)
Byte
Copy of 300003
400013*
Receiver value (8 bit)
Byte
Copy of 300004
400014*
Receiver value (10 bit)
Word
Copy of 300005
400015*
Fault register
Byte
Copy of 300006
400016
Gage upper tolerance
Byte
Gage high threshold % offset above cal pt1
400017
Gage lower tolerance
Byte
Gage low threshold % offset below cal pt1
400018
Controller Gain
Byte
Controller digital gain pot setting
400019
Probe Gain
Byte
Probe digital gain pot setting
400020
Gage high threshold
Byte
Boundary between accept and high reject
400021
Gage low threshold
Byte
Boundary between under and accept
400022
Gap threshold
Byte
Boundary between under and no-metal
400023
Frequency
Word
Current operating frequency
400024
DS600 active slot no
Byte
Memory slot number of current cal data
400025
Cal data access slot
Byte
Targeted calibration memory for read or
write
400026
Cal data array
20
Words
Calibration data array transfer buffer
400046
Total bus message cnt
Word
Modbus total message count since reset
400047
Handled message cnt
Word
Modbus successful messages since reset
400048
CRC error cnt
Word
CRC error occurrences since reset
400049
Exception response cnt
Word
Exception responses since reset
400050
No response msg cnt
Word
Messages not responded to since reset
400051
Character overrun cnt
Word
Character overrun errors since reset
400052
NAK response cnt
Word
NAK responses since reset
400053
Busy response cnt
Word
Busy responses since reset
