4 MODBUS COMMUNICATION (DS600PC Only)
4.1 Serial Interface
The Modbus serial protocol is a Master-Slave protocol where the DS600PC operates as a
Modbus slave that communicates with the master when a request is received. The DS600PC
operates in RTU transmission mode with its electrical interface in accordance with the EIA/TIA-
485 standard in a two-wire (half duplex) configuration at 38400 bps. The unit has a male M12
connector for connecting it to the bus. The interface is electrically isolated from all other power
and returns connected to the DS600PC unit.
Table 8 – Modbus M12 Connector Pinout
Pin
Function
Wire Color
Comment
1
No Connect
Brown
Unused
2
No Connect
White
Unused
3
Common
Blue
Isolated Modbus return
4
D0
Black
RS-485 A/A’
5
D1
Grey
RS-485 B/B’
4.2 Commands
Table 9 – Modbus Command Codes – DS600PC
Command
Code
Message Type
Meaning
1
Read coils
Bit reads from addresses 0000nn
2
Read discrete inputs
Bit reads from addresses 1000nn
3
Read holding registers
Register reads from addresses 4000nn
4
Read input registers
Register reads from addresses 3000nn
5
Write single coil
Bit writes to addresses 0000nn
6
Write single register
Register writes to addresses 4000nn
15
Write multiple coils
Bit writes to addresses 0000nn
16
Write multiple registers
Register writes to addresses 4000nn
