The controller is actively measuring a single metal
condition or the first of a two point calibration
The controller is waiting for the double metal condition to
be placed in front of the probe and a momentary press of
the Calibrate button to finalize the two-point calibration
There was an insufficient difference in the detected
metal between a single and double condition during a
two-point calibration
The controller requires factory service
The controller requires factory service
The selected calibration memory location is empty. Run
a calibration for this memory or select a memory that has
been calibrated.
Receiver amplitude too low. Recalibrate. Check all probe
wring.
Receiver amplitude too high. Recalibrate, Check all
probe wiring.
Unable to get probe ID. Probe is not properly connected
or has failed
Probe Connection Error. Verify probe cabling and
connections to the controller
Digital Pot pass-thru fault – Factory Service Required
DIP sw input shift register fault – Factory Service
Required
ID digit driver fault – Factory Service Required
LED driver fault – Factory Service Required
Three digit display driver fault – Factory Service
Required
Display LSD driver fault – Factory Service Required
Configuration input parameter (factory use)
Confirm configuration selection n (factory use)
System type input parameter (factory use)
Frequency input parameter (factory use)
