Primera LX610 User Manual

101
Section 7: Technical Specifications
PRINT SPEED
1
Pre-die cut media: Up to 4.5” per second
Digital die-cut speeds are dependent upon the image being cut
PRINT RESOLUTION
Up to 4800 x 1200 dpi
PRINT TECHNOLOGY
Thermal Inkjet
INK TYPES
Dye-based CMY, Pigment CMY
Label Types
Pre-die cut, continuous and black marks
STANDARD CONNECTIVITY
USB 2.0 (USB 3.0 compatible)
Print Width
(Digital Die Cutting)
0.5” (13mm) - 4.1” (104mm) Digital Die Cut media width is fixed at
4.1” However, smaller size labels can be cut from the 4.1” media.
Print Width
(Pre-die cut)
0.5” (13mm) - 5” (127mm)
Media Width
Pre die-cut: 2.125" (54mm) to 5.25" (133mm)
Digital Die-cut: 4.75" (121mm)
Maximum Print Length
12” (305mm)
Operating System
Windows 7, 8 or 10.
DIMENSIONS
13.6 W x 17” D x 9.5” H (345mm W x 432mm D x 242mm H)
WEIGHT
12.5 lbs (5.7kg)
POWER
Input: 100 – 240 VAC, 50/60 Hz, 60 watts, Output: 12 volt 5 amp
WARRANTY
One-year parts and labor; lifetime phone, chat and email support
Operating Temperature
50 to 95º F (10 to 35º C)
Recommended Operating
Temperature
61 to 87º F (16 to 32º C)
Storage Temperature
-4 to 140º F (-20 to 60º C)
Operating Humidity
10 to 60% RH (non-condensing)
Storage Humidity
10 to 80% RH (non-condensing)
Certifications
UL, UL-C, CE, FCC Class A
REPLACEMENT INK
CARTRIDGES
Primera Pigment 53491
Primera Dye 53494
