Primera LX900 User Manual

70 Troubleshooting and Maintenance
G. REPLACING THE PRINT HEAD
Regular replacement of the print head is not necessary.
However it may become necessary if you notice a gradual
decrease in print quality or if some of the print nozzles are
still clogged after repeated manual cleanings as described in
Section 5F.
Follow this procedure:
1. Press the Pause and Load/Feed buttons simultaneously to
move the print carriage to the center of the print area.
2. Remove all cartridges. Press the release tab at the front of
the carriage to release the latch.
Press Pause + Load/Feed
to Start and Finish.
Power
Ink
Pause
Load/
Feed
Unload

Primera LX900 Specifications

General

Print Technology	Inkjet
Interface	USB 2.0
Connectivity	USB 2.0
Media Sensing	Gap and black mark sensing
Supported Label Materials	Paper, Polyester, Polypropylene
Print Resolution	Up to 4800 dpi
Print Speed	Up to 4.5 inches per second
Max Print Width	8.25" (210 mm)
