Primus XCONTROL PLUS - 7 Pre-Programmed Programs; Legend

58 PROGRAMOVACÍ MANUÁL 540876_A_PUB_DATE_1_FEB_2012.DOC
7. PRE-PROGRAMMED PROGRAMS
The Wash Computer contains 20 pre-programmed Standard Wash Programs.
(Standard Programs : 1 to 20. Programs 21 to 57 are dedicated.)
ATTENTION!
THE PRE-PROGRAMMED PROCESSES ARE GIVEN AS AN EXAMPLE ONLY.
FOR THE CREATION OF YOUR OWN WASH PROGRAMS, CONTACT YOUR SOAP SUPPLIER.
7.1. LEGEND
 WATER INLETS (VALVES)
- Inlet Valve 1: Cold Soft Water Soap Dispenser Compartment „I“ Pre wash
- Inlet Valve 2: Cold Soft Water Soap Dispenser Compartment „II“ Wash - detergent
- Inlet Valve 3: Cold Soft Water Soap Dispenser Compartment „III“ Wash - liquid
- Inlet Valve 4: Cold Hard Water Soap Dispenser Compartment Last rinse
„Fabric softener“
- Inlet Valve 5: Hot Soft Water Soap Dispenser Compartment „I“ Pre wash
- Inlet Valve 6: Hot Soft Water Soap Dispenser Compartment „II“ Wash - detergent
- Inlet Valve 7: Cold Hard Water Direct Inlet (External liquid soap)
- Inlet Valve 8: Hot Soft Water Soap Dispenser Compartment „III“ Wash - liquid
 WATER LEVEL
- NL: Normal Low level
- NH: Normal High level
- EL: Economic Low level
- EH: Economic High level
 WASH ACTION
 Normal Wash Action
- A = 12“ 12 Seconds Action
- R = 3“ 3 Seconds Rest
 Gentle Wash Action
- A = 3“ 3 Seconds Action
- R = 12“ 12 Seconds Rest
 RPM (REVOLUTIONS PER MINUTE)
- W: Washing Speed ( 32 - 50 RPM)
- D: Distribution Speed (not changeable) ( 100 RPM)
- L: Low extraction speed, standard ( 400 RPM)
- H: High extraction speed ( 625 - 1165 RPM) (depending on the machine capacity)
!
