8.4. OVERVIEW
N° Failure message Failure Action Fault occurrence
E2
No Drain
Drain failure Full Stop + tumble Draining sequence
E3
Tilt Fault
Out of balance Full stop + tumble Whole cycle
E4
Imbalance
Out of balance :
Normal spin
Skip + continue After 5 x tilt
E5
Tilt High Sp
Out of balance : high
spin
Full stop + safety time >500 or 750 RPM
E6
Door Switch
Door switch failure Full stop + safety time Whole cycle
E7
Door Coil
Door lock switch
failure
Full stop + safety time Whole cycle
E8
Door Start
Door lock check at
start failure
Don’t start At start up
E9
Door Unload
Door lock switch
closed failure
Don’t start End cycle
E11
No Fill
Fill failure Full stop + request for
Continue
While filling
E12
Overfill
Overfill failure Full stop + tumble While filling
E13
No Heating
Heating failure Full stop + tumble While heating
E14
Heat Time
Heating time failure Full stop + request for
Continue
While heating
E15
Too Hot
Too Hot Full stop + tumble While heating
E21
Overflow
Overflow failure Full stop + tumble Wash step
E24
Level Sens
Defective level sensor Continue + Don’t start Before start up
E25
Temp Sensor
Defective temperature
sensor
Continue + Don’t start Before start up
E26
Mitsub code
Undefined frequency
inverter error code
Full stop + tumble Whole cycle
E27
Comm fault
Communication fault
inverter
Full stop + safety time Whole cycle
E28
THT time / E.OL
THT Time out / E.OL Full stop + safety time At spin sequence
E29
OV3 time / E.OP
OV3 Time out / E.OP Full stop + safety time At spin sequence
E31
Load Parr
Initialization fault
inverter
Don’t start At initialization
E32
Verify Parr
Verification fault
inverter
Don’t start At loading parameters
E35 Wrong Softw
Wrong software
version
Don’t start New software version
E37 No Drain Sp
Drain failure at the
Spray Sequence
Full stop + tumble Spray Sequence
E39 Out of Soap
The Soap Supplies
are running Out of Soap
For Info only Wash step
E41 Service Due
Service Due Warning For Info only
Open door = reset
End cycle
E42 Connection
No Network
Connection
For Info only Data Transfer Networking
E43 Voltage Par
Wrong Voltage
Range Selection
Make correct selection Configuration menu
E80
Time Out Input16
On Hold Signal Failure
Soap Dispensing
System
Full stop + tumble. Whole cycle
E81
No Reheat
Heating Failure Full stop + tumble.
Wash Step
(Traceability only)
E82
No Refill
Refill failure Full stop + request for
Continue
Wash Step
(Traceability only)
