76 PROGRAMOVACÍ MANUÁL 540876_A_PUB_DATE_1_FEB_2012.DOC
TOOLBOX MENU
The purpose of the Toolbox Menu is to give support at technical interventions.
Menu Item Info
View Input States ?
1 Input 1 On
…
20 Input 20 Off
The Input states for Input 1, …, Input 20.
The exact function of the inputs can be found on the
electrical drawing of the washing machine programmer.
- if the Input state is Off, the Input signal is low.
- if the input state is On, the Input signal is high.
Imbalance Statistics …
Imbalance …
1 ...0,5 0
...
31 > 15 0
Current …
1 I0 0
...
4 I3 0
Diagnostic information on imbalance of the machine.
Inverter Power Off By this function it‘s possible to switch on the power of
the inverter if a technical intervention is needed.
Attention!
SPECIAL CARE HAS BEEN TAKEN AT THE INITIALIZATION
OF THE PARAMETERS OF THE FREQUENCY INVERTER.
THE MANUFACTURER IS NOT RESPONSIBLE FOR THE
WRONG BEHAVIOR OF THE WASHING MACHINE IF THE
OWNER HAS INSTALLED NEW PARAMETER SETTINGS IN
THE INVERTER THAT DO NOT CORRESPOND WITH THE
ORIGINAL SETTINGS AT THE FACTORY.
Pulley Ratio X.XX The Pulley Ratio allows to verify if the motor pulley
and the drum pulley have the correct size by
calculating the pulley ratio.
RTC Time XX:YY:ZZ
The Time value of the Real Time Clock.
XX : Hours, YY : Minutes, ZZ : Seconds
RTC Date AA:BB:CC
The Date value of the Real Time Clock.
AA : Day, BB : Month, CC : Year
Adjust Clock …
Hour XX
Minutes YY
Day AA
Month BB
Year CC
Set the correct Date and Time for the RTC.
!
