Chapter 9 Configuration Screens
202
The following displays:
3. Select TN3270E Mode.
The following displays:
NOTE: Changes will only take effect after you reset the line matrix
printer from the System page.
4. Enter the address of your system for the host IP address
The port address is the port configured for your telnet server. It is
usualy port 23.
The Resource name will be the printer name defined in the VTAM
portion of your Telnet server configuration. For this example use
RMT3.
Mode: TN5250 Click here for TN3270 mode
Host ok (eg. 204.191.175.114 or
host.domain.com)
Port
Device Description
Message Queue Name
Message Queue Library
Device Type GENERIC PRINTER
WSCST Name
WSCST Library
Auto Connect
Start Auto Connect Click here
Configuration for Print Path d2prn
Mode: TN3270 Click here for TN5250 mode
Host ok (eg. 204.191.175.114 or
host.domain.com)
Port 23
Resource Name
Auto Connect
Stop Auto Connect Click here
