Chapter 2 Set The Top-of-Form
52
5. Locate the TOF indicator (
3). It is a small tab located on both
the right and left tractor door.
6. Turn the vertical position knob (5) to align the top of the first
print line with the TOF indicator. For best print quality, it is
recommended that top-of-form be set at least 1/2 inch below
the perforation (4).
3
5
4
