8 Specifications
Front Panel
Instrument inputs 1&2:
Two 6.3mm mono jack sockets [*Note1]
Headphone output:
6.3mm stereo jack socket, with illuminated volume control
Master volume control:
Assignable to any selection of outputs, with LED halo indication
Level meters:
Multi-segment, multi-color bargraphs with overload indication; two for
analog, two for digital, assignable to inputs or outputs (analog output
switchable 1/2 or 3/4) [*Note1]
Input selector
indicators:
Indicate modes of analog inputs 1-2 as mic/line/instrument; plus phantom
power indicator for mic mode
Overkiller-active
indicators:
For each analog input, lit when Overkiller limiters are acting
Digital input indicators:
Input unlocked, and SRC (sample-rate converter) selected
Digital output indicator:
SRC (sample-rate converter) selected [*Note1]
Sync indicator:
Master, lit when interface is in local sync
Standby button:
With standby indicator (also flashes when unit is in 'identify' mode)
Rear Panel
Mic inputs 1-2:
Two XLR sockets for mic input [*Note1]
Line inputs 1-2:
Two 6.3mm TRS jack sockets (balanced or unbalanced)
Line outputs 1-4:
Four 6.3mm TRS jack sockets (balanced or unbalanced) [*Note1]
Digital inputs:
RCA socket for S/PDIF in, TOSLINK for S/PDIF or ADAT/SMUX in; (RCA
can operate as AES3 input using XLR-RCA adapter supplied) [*Note1]
Digital outputs:
RCA socket for S/PDIF out, TOSLINK for S/PDIFor ADAT/SMUX out;
(RCA can operate as AES3 output using RCA-XLR adapter supplied)
[*Note1]
Wordclock I/O:
Two BNC sockets, output and input (75R) [*Note1]
USB port:
Ethernet port:
USB 2.0 B type device socket
RJ45 100BaseT socket, for factory and future use [*Note1]
Mains power:
3-pin 6A IEC inlet
Software Support
Mac OS support:
OS X 10.5 or later, Intel platform
Windows OS support:
Windows Vista, 7, 8 or later (32 or 64 bit)
Mac audio driver:
Core Audio device
Windows audio driver:
ASIO or WDM device
Control Panel app:
Graphical user interface for control of Lyra unit under Mac OS X or
Windows
