Slim Panel Connections
48
This figure shows the dimensions of the AC power supply module:
AC Power Supply
The table provides technical data for the AC power supply module:
Operation temperature of the AC power supply derating curve:
Element Characteristics
Input 90...260 Vac / 47...63 Hz / 1.6 A at 100 Vac
Output 24 Vdc / 2.62 A maximum
Inrush current 70 A at 230 Vac
Environment
Operation temperature 0...70 °C (32...158 °F), see derating curve
Storage temperature -40...85 °C (-40...185 °F)
Relative humidity: 0...95 %, non-condensing
