Configuration of the BIOS
58
Optional IMT Configuration Submenu
Optional COM2 Configuration Submenu
Optional EC Watchdog Configuration Submenu
Device power-up delay Select device power-up section. Maximum time the device takes before it
properly reports itself to the host controller. Auto uses a default value: for a
root port it is 100 ms, for a hub port the delay is taken from the hub
descriptor.
BIOS setting Description
BIOS setting Description
CPU Shutdown Temperature Select CPU shutdown temperature.
IMT WatchDog IRQ Select iManager IRQ number eBrain watchdog.
Backlight Enable Polarity Switch backlight enable polarity for native or invert.
Hardware Monitor –
BIOS setting Description
COM2 UART mode setting Select RS-232 or RS422/RS485 mode. The default setting is RS-232 mode.
BIOS setting Description
EC Watchdog setting Select EC watchdog setting.
