10
8
9
94
8. Tighten an M4 x 15mm Blunt Screw (94) into the
underside of the Handlebar Post (9).
9
59
90
K
5
F
F
9. Locate the wire tie (F) inside of the Console
Mount (5). Tie the lower end of the wire tie to the
Upper Wire (90). Then, pull the upper end of the
wire tie until the Upper Wire is routed through
the Console Mount.
Next, slide a Grommet (59) onto the Upper Wire
(90), and press the Grommet into the underside
of the Console Mount (5).
