Set 7 Day Program Schedule
Programming Programming
A Note About Auto Changeover:
When in Auto you have the ability to switch between auto heat or auto
cool by pressing the system key. This can be done once the current
mode has reached its setpoint. For example: if in auto heat, the heat
setpoint must be satised before the thermostat will allow you to switch
to auto cool. You can switch out of auto by holding down the system
key. To get back into auto, you must toggle the system key to auto.
1. Select HEAT or COOL with the SYSTEM key.
Note: You have to program heat and cool each separately.
2. Press the MENU key.
3. Press SET SCHED. Note: Monday is displayed and the
WAKE or OCCUPIED icon is shown. You are now programming
the WAKE or OCCUPIED time period for that day.
Monday:
4. Use the or key to make your time
selection for the weekday time period.
Note: If you want the fan to run continuously during this time
period, select ON with the FAN key.
5. Then use the or key to make your setpoint selection for
that weekday period.
6. Press Next Step.
7. Repeat steps 4 through 6 that day’s other time periods.
Repeat steps 4 through 6 for Saturday time periods.
Saturday:
Repeat steps 4 through 6 for Sunday time periods.
Sunday:
Additional step if indoor remote sensor is connected.
The master thermostat will either average all sensors (system average)
or only use one sensor for the system ambient temperature (priority).
The default setting is SYSTEM AVERAGE, which means all sensors are
averaged to create the system average ambient temperature reading.
The NEXT ZONE key can be pressed to change the priority. The system
information area of the display shows the priority. For Example: There is
a remote connected and it is named REMOTE 1. If the NEXT ZONE key is
pressed until REMOTE 1 is shown, then the REMOTE 1 ambient
temperature reading will be used exclusively for that time period. All
other sensors will be ignored.
Continued on next page...
