Procopi Delta STARDECK User Manual

2009/02 - Indice de révision : D - code : 0035431
60/76
PRODUCT DESCRIPTION
1 - Sub-coping mounting plates (Coverdeck pit partition only, comes with beam mounting units)
2 - Coverdeck or Stardeck flange
3 - Seperating pit wall for straight wall pools
4 - Seperating pit wall cut to fit shaped walls (exemple here; trapezoidal)
NOMENCLATURE
Ref Description Quantity
STRAIGHT WALL
a Upper section with internal reenforcing bar and profiled trim 1
b Sections with right angle corners depends on the pool shape
c Sections with cut corners 1
Screw kit (lug nut + washer + nylon screw 60 M10)
TRAPEZOIDAL WALL (Cut to fit the pool wall shape)
Sections cut to shape Depends on the pool shape
Profiled trim
d Plats**** 2 or 3 depending on pool width
Rivets
REQUIRED TOOLS (BESIDES THOASE AVAILABLE IN AN ORDINARY TOOL BOX )
- Riviting tongs
- Mallet
- Ompact drill
- Tape measure
- Drill bit, 5 mm
- Drill bit, 13 mm
- Allen key, no 5
- Phillips head pozidrive screwdriver no. 2
1
2
3
4
a
b
c
d
