Start with the housing slats on the pool side
On IGLOO II housings, lthe motor should be positioned upside down (head down).
9
Fitting the motor onto the motor bearing
Electrical cables
Inserting the U-shaped pin
Mounting the junction boxFixing the aluminium bracket in position
A B
C D
CLIPPING ON THE HOUSING SLATS
MOUNTING THE MOTOR
Caution: Ensure that the pins is correctly positioned
