OperatingtheDSO480
PreliminarySet‐up

TheprocedurebelowshouldbefollowedwhenfirstinstallingaDSO480unit.
 Designyourcrossover!Todothis,pressMENU,andusetheBACKorNEXTkeytoselect
‘Crossover sub-menu’andthenpress
ENTER.UsetheBACKorNEXTkeytoselect
‘Design a crossover’andthenpress
ENTER.Finally,usetheBACKorNEXTkeytoselect
thedesiredrouting
1
andfollowtheset‐upwizardtofinaliseyourdesign.

 Notethatwheninamenu,
ENTERisalwaysusedtoconfirmselections.Thecurrentselectionis 
markedwithanasterisk‘*’.

 Usethe
EDITkeysoneachoutputchannelwiththeBACKandNEXTkeystoselectthehighpass
filters,lowpassfilters,parametricsetc.Notethatwhendesigninganewcrossover,thehighand
lowpassfilterswillbesettodefaultvalues.

 UsetheEDITkeysoneachinputchannelwiththeBACKandNEXTkeystoselectthegain,delay
andparametricsavailableoneachinput.
Info: Note that if no action is taken in menu mode, the unit will return to normal ‘default’ mode
after about twenty (20) seconds. Repeat the above directions to return to menu mode.
1
For details about adjusting the routing if one of the standard configurations does not suit, see page 15.
