PROEL DSO480 - Digital Input and Software Update; Loading New Software via a PC; AES Input

26
LoadingNewSoftwareviaaPC

Theunit’sinternalsoftwaremaybeupdatedviatheRS232portONLY,oneunitatatime.Werecommend
disconnectingallotherdeviceswhenupdatingthesoftware.

Theunit’sinterfacemustbesetasRS232MasteronID1forthePCloaderprogramtorecogniseitandallow
theupdatetobesent.

Downloadth
elatestversionoftheloaderprogramandtheunitsoftwarefromwww.proelgroup.com,and
followtheinstructionsincludedwiththiszipfile.

AESInputs
TheDSO480 unitshaveafullAESimplementationbuiltinasstandard.Thisallowstheunittobothreceive
digitalaudiodirectly,andtotransmitdigitalaudioontootherdevices.Theswitchingofinputandoutputcan
beperformedindependently,andtheinclusionofsamplerateconvertersontheinputsallows theunitto
accep
tsampleratesfrom32kHzupto192kHz.

AESInput

Inputselectionisviaarecessedswitchontherear
paneloftheunit,betweeninputDandoutput1.A
redLEDinsidethisapertureilluminatestoshowthat
theAESdigitalinputshavebeenselected.
AcomplimentaryLEDonthefrontpanelalso
illuminates.TheswitchcontrolstherearpanelLED
directly,whilstthefrontpan
eloneisviathe
processor,allowingittorelayalittlemore
information.
Ifitisflashing,thismeansthatAESinputshavebeen
selectedbuthavenotlocked.OnceastableAES
signalisbeingreceived,itwillbepermanently
illuminated.





TheAESinputsaremarkedontherearpanel–
forchannelsA&BuseinputA,
andforchannelsC&DuseinputC.





