All Pass Filter

InA Input A APF:1 0
1k00Hz Q=3.0 Allpass

Remember–tochangefiltertypes,pressBYPASSto
bypassthefilter,andthenuseENTERtoselectthefilter
type.

Theallpassfilterhasadjustablefrequencyand‘Q’(or
Bandwidth)controls.Theseaffectthefrequencyat
whichthephaseeffectivelyflips180°,andthe‘speed’at
whichth
istransitionoccurs.

Thegraphshowsanallpassfiltercentredat1kHz,with
various‘Q’settings–thehigherthe‘Q’thefasterthe
transition.






Phase Filter

InA Input A PHS:1 0
1k00Hz 150° Phase

Remember–tochangefiltertypes,pressBYPASSto
bypassthefilter,andthenuseENTERtoselectthefilter
type.

Thephasefilterhasadjustablefrequency,andphase
shiftcontrols.Thisintroducesaphaseshiftthat
graduallychangesfrom180°abovethecentre
frequencytothespecificedvalueatthecen
tre
frequency,andtendingtowards0°belowthecentre
frequency.

Thisgraphshowsthephaseshiftrelativetotheinput 
(ignoringprocessingdelays),in10°steps–thefilterwill
actuallyprovidehigherresolutionthanthis,operatingin
2°steps.Thefilteriscentredat1kHzinthisexample.

