Editing Audio Parameters – Output Channels
OutputGain
The range of the control over the input gain is –40 dB to +15 dB in 0.1 dB steps.
OP1 Output 1 Gain
Output Gain = +6.0dB
Gain
OutputPolarity
Thepolarity(orphase)ofeachoutputmaybeswitchedindividuallyasbelow.
OP1 Output 1 Polar.
Polarity = [+]
- or +
OutputDelay
Themaximumavailabledelaybetweenanyinputandoutputis650.00ms.Forexample,iftheinputdelay
onchannelAissetto500ms,themaximumavailableoutputdelayforanyoutputfedfrominputAwillbe
150ms.Thereadoutunitscanbechangedbetweentimeinmillise
conds,distanceinfeetordistancein
metres.Pleaseseepage23formoredetails.
OP1 Output 1 Delay
Delay = 0.0000mS
x 1mS x 10uS x0.3uS
343mm 4mm 0.1mm
