15. Far scivolare il Copri Gamba Base Sinistro (101)
sulla Base (48) come mostrato. Attaccare il Cop-
ri Gamba Base Sinistro con tre Viti da 1/2” (6).
Fare attenzione a non stringere troppo le Viti.
6
48
6
6
15
16. Avvitare una Vite da 1/2” (6) nel ciascun lato
della Base (48) e nel ciascun Copri Gamba
Base (101, 102). Fare attenzione a non strin-
gere troppo le Viti.
6
102
101
48
16
101
14. Attaccare il filo messa a terra sul Filo Montante
(28) al foro indicato nella Base (48) con una Vite
M
essa a Terra in Argento (27).
P
remere il gommino di protezione indicato nel
Montante Destro (36).
Far scivolare il Copri Gamba Base Destro (102)
sulla Base (48) come mostrato. Attaccare il Copri
Gamba Base Destro con tre Viti da 1/2” (6). Fare
attenzione a non pizzicare il Filo Montante
(28). Non stringere troppo le Viti.
102
48
28
36
6
6
Gommino di
P
rotezione
Filo Messa a Terra
6
1
4
27
