Figure 17 System Diagram
4. WIRING
4.1 Material
CODE NAME MODEL/LENGTH QTY P/NO. ON
DRAWING
1 Caravan Master Power PM235 11
2 Membrane Switch Panel PMSWLED 13
3
Fresh water tank level sensor
Not included and
to be ordered
separately
04
4 Tap water tank level sensor 06
5 Waste water tank level sensor 07
6 PV 09
CODE NAME MODEL/LENGTH QTY P/NO. ON
DRAWING
7 Switch panel line 5m 1 PMSWLEDC
8 Battery sensor line 3m 1 PMBS
9 Water tank probe line 4m 0 PMWS200 /
PMWS400
10 Water tank probe line 4m 0
11 Water tank probe line 4m 0
12 Power Cable 1.5m 1 PMAC
Table 6 Components list of PM200
4.2 System Schematic
Solar
Switch Panel
PMWS200 /
PMWS400
PMWS200 /
PMWS400
PMWS200 /
PMWS400
PMBS
PMAC
PMSWLEDC
To Next Page
