17
6.2 Daily maintenance
• Confirm the Battery Switch is switching on when you want to charge the battery with the AC grid.
• Check the nominal battery voltage is 12Vdc.
• Ensure the space (10cm each side) beside the PM235 unit for the good ventilation.
DIP SWITCH DESCRIPTION
Local The switch on PM235 unit works
Remote The remote switch works and local one is disabled
Figure 24 Local/Remote Select Switch Table 16 Local/Remote Setting
Local
Remote
6.1.2 Select Battery Switch Local/Remote
This function offers a possibility for user to use a remote battery switch to power on/off the service battery output
It is recommended to switch off the local Battery Switch on main panel of PM200 master power
unit or remote switch to cut off the consumption of the service battery.
