19
8. SPECIFICATION
Table 18 Specification of PM235
MODEL PM235
ELECTRICAL SPECIFICATIONS
Grid Nominal input voltage
(V)
240±10%VAC
50/60Hz
Power factor 0.95
Input current at full
load
2.5A
Battery Starter Battery 12VDC
Starter battery voltage
range
12.8-16VDC
Service battery 12VDC
Service battery
voltage range
10.5-16VDC
PV Charger type PWM
Open circuit voltage 25VDC
Max supply current 30A
Max charging current 20A
Charging
Relay
Relay specification 12VDC 60A
continuous,
peak current
100A, 30mins
Connect voltage 13.4V
Connect delay time 10sec
Disconnect voltage 12.8V
Disconnect delay time 60sec
High voltage limit 16.0VDC
Charger
Mode
Charge Algorithms 5 Stage
Battery type AGM/GEL/
LiFePO
4
/WET
Start voltage 2V
Bulk current 20A (Max)
Absorption voltage (14.4/14.1
/14.4/14.7)
±0.15VDC
Float voltage (13.5/13.5
/13.5/13.7)
±0.13VDC
Power
Supply
Mode
Nominal output
voltage
12.8±0.2 VDC
Rated output current 35A
(Continuous)
Efficiency 88%
Working temperature -40°C~+65°C
(50°C: full load;
60°C: 20A;
65°C: shutdown
the output)
MODEL PM235
OTHERS
Battery
Disconnect
(LVD)
Disconnect voltage AGM/GEL/WET 10.5VDC
(default)
LiFePO
4
11.2 VDC
(Default)
Delay off time 60 sec
Reconnect voltage AGM/GEL/WET 11.5VDC
(default)
LiFePO
4
12.2 VDC
(Default)
Current draw
on battery
240VAC is off, no
vehicle charging
405mA
LVD battery <10.5
current draw on
battery
110mA
LVD battery <10
current draw on
battery
0mA
Fused outputs Numbers 14
Rated current 15A x 4: 10A x 10
Protection Short circuit on output Fuse blown
Reverse polarity Diode reverse isolation
Overload protection Derate the output until overload
is removed
Battery charger over
temperature
Shut down PM235
Ambient over
temperature
Alarm
Battery over voltage
limits
Battery charger disconnect,
loads disconnect
PHYSICAL SPECIFICATIONS
Dimensions
(L*W*H)
264 × 164 × 128mm
Weight 3kgs
Enclosure Steel case
Battery
Connector
M4 Screw (16mm
2
)
Load Connector Wago804-114 (2.5mm
2
)
Cooling Forced cooling
Protection
category
IP20
Approvals
Electrical AS/NZS 60335-2-29
EMC CISPR14
