5.6.4 RS232/USB Main Menu
The RS232 / USB menus are hierarchical. Press ENTER to access main menu as shown in Figure 20. Type in the
number of submenu and press Enter button to access a particular submenu. Press Enter to refresh the screen,
the Status, Faults, and Alarms readouts.
Note: It’s requested to enter passwords in 8 Login Administrator first to access submenu 3~7. The factory
default password is 1111.
The main menu displays the submenu numbers, the line status, the unit’s output status and any faults or alarms
that may be present.
ID: 92611310100001
[0-MAIN MENU]
1 Unit Specification
2 Input / Output Values
3 Control
4 System Setting
5 Line Conditioning Setup
6 Programmable Contacts Setup
7 Event Log View
8 Login Administrator
Date & Time : 13-10-14, 09:24:02
Sense Type : [Normal]
Line Status : Not Good
Output Status : Inverter
Contact Status :
Contact C1 ==> [ON BATT]/[Activated]
Contact C2 ==> [ON BATT]/[Activated]
Contact C3 ==> [LOW BATT : 46.0 Volts]/[Not Activated]
Contact C4 ==> [LOW BATT : 46.0 Volts]/[Not Activated]
Contact C5 ==> [Timer : 2.00 Hours]/[Not Activated]
Contact C6 ==> [Timer : 2.00 Hours]/[Not Activated]
Ext.Fan Status : [Activated]
Faults : None
Alarms : Line Fail/BTS Disconnect
Figure 20: Main Menu Screen
