Displayed contents of Line Status, Output Status, Faults and Alarms are listed in Figure 21.
▼
Line Status Displays
Output Status Displays
Fault Displays
Alarm Displays
Normal
Self Test
Bus Voltage Over
Bus Voltage Over
Not Good
Inverter
Bus Voltage Under
Bus Voltage Under
Buck
Bus Soft Fail
Bus Soft Fail
Boost
Output Short
Line Fail
Normal
INV Output Voltage Low
Output Short
Off
INV Output Voltage High
INV Output Voltage Low
Over Temperature
INV Output Voltage High
Contact Status/ Ext. Fan
Status Displays
Fan Fault
Over Temperature
Battery Voltage High
Fan Fault
Activated
Over Load
Battery Voltage High
Not Activated
Battery Voltage Low
Over Charge
Battery Voltage Under
Temp Derating
Over Load
Eeprom Fault
Battery temperature low
Battery temperature high
BTS Disconnect
Battery Disconnect
Site Fault
Figure 21: Displayed contents in Main Menu
Line Status: [Current Status]
Output Status: [Current Status]
Contact Status: [Current Status]
Ext. Fan Status: [Current Status]
Faults: [If any, otherwise blank]
Alarms: [If any, otherwise blank]
>_
