PROLiNK PRO2000LD User Manual

24
5.6.5 Unit Specifications
To access Unit Specification menu, type 1 and press Enter on the main menu. To return to the main menu,
press Esc and then press Enter buttons.
It lists unit specifications as following table.
[ 1 - Unit Specifications ]
Unit Model
The model name
Unit Freq
Nominal operating frequency
Input Voltage
Nominal input voltage
Output Voltage
Nominal output voltage
Output VA
The output capacity in VA
Battery Voltage
Nominal battery voltage
Max Charge Current
Maximum charging current
Panel Firmware Version
Panel board firmware version
Main Firmware Version
Main board firmware version
Hardware Version
Hardware version
5.6.6 Input/Output Values
To access Input/Output Values menu, type 2 and press Enter on the main menu. To return to the main menu,
press Esc and then press Enter buttons.
Following table lists the actual measurements of input / output parameters.
[ 2 – Input / Output Values ]
Input
Voltage
The Input voltage
Freq
The Input frequency
Output
Voltage
The output voltage
Freq
The output frequency
Power
The output active power
VA
The output apparent power
Load Per
The load percent of output power
Battery
Temperature The ambient temperature of the battery case as read via attached temperature
probe.
Voltage
The battery DC voltage
Evt-Timer
INV Event
The number of times that input power failure occurs
INV Timer
Total time that the battery was discharged since the latest RESET
BUCK Event
The number of times that BUCK function activates
BUCK Timer
Total time that the BUCK function activates since the latest RESET
BOOST Event
The number of times that BOOST function activates
BOOST Timer
Total time that the BOOST function activates since the latest RESET
