FM15_P28 HV PN7 (-TS) Ver I_052217
Page 9 P2/3 HV-PN7 Series
Follow these instructions to adjust the CW position controlled by the 105 Proportional Controller (standard operation).
Proceed to the next page to adjust the CW position controlled by the travel cam.
(Assumes actuator is powered up, running and is at the default display, showing position).
Notice Performing an Auto Calibration after this procedure will ERASE this custom stop set point and will return to the
factory default setting. For this reason, you CANNOT run an Auto Calibration procedure at any time after this setting has
been changed.
Press the joystick LEFT twice... Display reads:
Press the joystick DOWN three times... Display reads:
Press the joystick RIGHT once... Display reads:
Press the joystick DOWN once... Display reads:
Press the joystick RIGHT once... Display reads:
(actual position in steps)
Press joystick UP and HOLD to drive further CCW or press DOWN
and HOLD to drive further CLOSED. The adjusted CLOSED position
MUST be between 50 and 1000 steps.
When the correct CLOSED position is established,
press the joystick IN... Display reads:
Press the joystick LEFT twice... Display reads:
Press the joystick UP three times Display reads:
Press the joystick RIGHT once... DOWN twice,
then RIGHT once, the display will now show %
of CCW position (0.0 = Fully CW)
SET Travel
Auto Set
Full Closed
done
SET travel
00 to 100
00 to 4096
realtiOe
realtiOe
Controller: Adjusting the actuator CW position
