After completing all mounting and wiring procedures and main power is available, it is now possible to commission
the actuator.
1. Utilize the handwheel to rotate the actuator and damper, valve or other connected device through its full travel from
fully CW to fully CCW and back again to check for any possible interference.
• Do NOT utilize any mechanical advantage devices to rotate the handwheel (pipes, wrenches, extension bars, etc.).
2. Manually position the actuator to its mid-stroke position.
3. Make certain the 3 wire plug is fully seated on the 3-pin receptacle on the switch board.
4. Apply correct power to the unit.
4.A Measure correct power on terminals 1 (Hot / L1) & 2 (Neu / L2) on the switch board.
4.B Measure correct power on the two heater terminals on the switch board.
5. CommandthefielddevicetogenerateaCCWsignal.TheactuatorrotatesinaCCWdirection(asviewedfromabove).
• Measure terminals 2 and 6 for correct voltage (matching that measured in step 4.A).
• Actuator will stop when it reaches it’s fully CCW position.
6. CommandthefielddevicetogenerateaCWsignal.TheactuatorrotatesinaCWdirection(asviewedfromabove).
• Measure terminals 2 and 4 for correct voltage (matching that measured in step 4.A).
• Actuator will stop when it reaches it’s fully CW position.
7. Actuator is now commissioned and operational.
P2~13 Series 120/230VAC
Page 18 P2/3 HV-PN7 Series
Commissioning
