Promation Engineering P2 Series - Controller: Adjusting the Actuator CCW Position

FM15_P28 HV PN7 (-TS) Ver I_052217
Page 11 P2/3 HV-PN7 Series
Follow these instructions to adjust the CCW position controlled by the 105 Proportional Controller (standard operation).
Proceed to the next page to adjust the CCW position controlled by the travel cam.
(Assumes actuator is powered up, running and is at the default display, showing position).
Notice Performing an Auto Calibration after this procedure will ERASE this custom stop set point and will return to the
factory default setting. For this reason, you CANNOT run an Auto Calibration procedure at any time after this setting has
been changed.
Press the joystick LEFT twice... Display reads:
Press the joystick DOWN three times... Display reads:
Press the joystick RIGHT once... Display reads:
Press the joystick DOWN twice... Display reads:
Press the joystick RIGHT once... Display reads:
(actual position in steps)
Press joystick UP and HOLD to drive further CCW or press DOWN
and HOLD to drive further CW. The adjusted CCW position MUST be
between 2500 and 4000 steps.
When the correct CCW position is established,
press the joystick IN... Display reads:
Press the joystick LEFT twice... Display reads:
Press the joystick UP three times Display reads:
Press the joystick RIGHT once... DOWN twice,
then RIGHT once, the display will now show %
of CCW position (0.0 = Fully CW)
SET Travel
Auto Set
Full open
done
SET travel
00 to 100
00 to 4096
realtiOe
realtiOe
Controller: Adjusting the actuator CCW position
