FM15_P28 HV PN7 (-TS) Ver I_052217
Dimensional Data P2~8-N7 Series Actuators: inches (mm)
A A
ts
B B
ts
C D E F G H I
P2~P3
14.0 (355) 15.5 (392) 9.0 (229) 10.5 (267) 9.7 (247) 3/4” NPT 5.8 (146) 3.4 (88) 9.8 (249) 14.1 (359) 4.8 (123)
P4~P6
16.7 (423) 19.2 (488) 10.8 (275) 13.4 (340) 11.2 (285) 3/4” NPT 7.3 (184) 5.0 (126) 11.5 (291) 15.3 (389) 7.6 (194)
P7~P8
14.9 (377) 18.4 (468) 9.0 (226) 12.6 (320) 11.2 (285) 3/4” NPT 9.3 (236) 5.0 (126) 11.5 (291) 18.8 (478) 11.6 (295)
J K L M N O W X Y Z
P2~P3
3.5 (90) M8 - 1.25 x 0.8” D 2.8 (70) F07 .866 (22.0) 8.0 (203) 1.18 (30.0) .866 (22.0) .866 (22.0) 1.18 (30.0)
P4~P6
4.9 (125) M10-1.50 x 0.8” D 4.0 (102) F10 1.378 (35.0) 8.0 (203) 1.89 (48.0) 1.378 (35.0) 1.378 (35.0) 1.58 (40.0)
P7~P8
7.1 (180) M12-1.75 x 1.0” D 4.9 (125) F12 1.417 (36.0) 8.0 (203) 1.93 (49.0) 1.417 (36.0) 1.417 (36.0) 1.77 (45.0)
Dim X and Y Tolerance: +0.000” -0.005” (+0.00mm -0.13mm)
1
1
2
2
A A
B B
Drawn By
Finish
Promation Engineering Inc.
16138 Flight Path Drive
Brooksville, Fl 34604
Phone: 352-544-8436
Fax: 352-544-8439
This Document is the property of ProMation Engineering,
Inc. Distribution of this document without the written
consent of the owner is Strictly forbidden.
Failure to comply will incur a liability for Damages.
Checked By
11/12/2014
P2~P8 Ex Dim Data
Rev.
E
NO SCALE
Sheet Number: 1
Material
ProMation Engineering, Inc.
KHL
KHL
8/13/2014
P2~P8 TS Ex Generic DimData.idw
Created:
Last Checked:
Part No.
Dwg. Name
Dimensional Data for P2~P8 Ex Actuators
Engineering Change Notice
Change Date
Description
Name
08.13.2014
New Document for P2~P8 TS and non-TS Ex Actuators
KHL
10.07.2014
Pushed N dimension to three decimal places
KHL
11.10.2014
Added "O" dimension - cover clearance
KHL
11.11.2014
Edited Views, variab
les and tolerances
KHL
11.12.2014
Corrected Values in table, formatted location of drive coupling fabrication
KHL
REV
A
B
C
D
E
F
Dimensional Tolerances (Unless Otherwise Noted):
X
± 2.5mm [X.X ± .1]
X.X ± .3mm [X.XX ± .01"]
X.XX ± .13mm [X.XXX ± .005"]
ALL TOLERANCE FEATURES IN mm
Drive Coupling Fabrication Data
Y
X
Z
W
A (A' = with Torque Switches)
B (B' = with Torque Switch)
I
J
G
H
FE
Ø L
Bolt Hole Circle
N
M ISO Flange
(4) K
(2) D
C
Ex
Dimensional Data P2~P8 Ex Actuators: in (mm)
-
A
A'
B
B'
C D E
P2~P3
14.0
(355)
15.5
(392)
9.0
(229)
10.5
(267)
9.7
(247)
3/4" NPT
5.8
(146)
P4~P6
16.7
(423)
19.2
(488)
10.8
(275)
13.4
(340)
11.2
(285)
3/4" NPT
7.3
(184)
P7~P8
14.9
(377)
18.4
(468)
9.0
(226)
12.6
(320)
11.2
(285)
3/4" NPT
9.3
(236)
F G H I J K L
P2~P3
3.4
(88)
9.8
(249)
14.1
(359)
4.8
(123)
3.5
(90)
M8-1.25
x 0.8" D
2.8
(70)
P4~P6
5.0
(126)
11.5
(291)
15.3
(389)
7.6
(194)
4.9
(125
)
M10-1.5
x 0.8" D
4.0
(102)
P7~P8
5.0
(126)
11.5
(291)
18.8
(478)
11.6
(295)
7.1
(180)
M12-1.75
x 1.0" D
4.9
(125)
M N O W X Y Z
P2~P3 F07
0.866
(22.00)
8.0
(203)
1.18
(30.0)
.866
(22.00)
.866
(22.00)
1.18
(30.0)
P4~P6 F10
1.378
(35.00)
8.0
(203)
1.89
(48.0)
1.378
(35.00)
1.378
(35.00)
1.58
(40.0)
P7~P8
F12
1.417
(36.00)
8.0
(203)
1.93
(49.0)
1.417
(36.00)
1.417
(36.00)
1.77
(45.0)
Dim X and Y Tolerance: +0.000" -0.005" (+0.00mm -0.13mm)
Handwheel Handle
not present on
P7/8 Actuators
O
Height needed
for clearance
ts
ts
Page 16 P2/3 HV-PN7 Series
Mechanical Data
