Promation Engineering P2 Series - Controller: Change Loss of Signal Response Setting

FM15_P28 HV PN7 (-TS) Ver I_052217
Page 13 P2/3 HV-PN7 Series
Press the joystick LEFT twice... Display reads:
Press the joystick DOWN twice... Display reads:
Press the joystick RIGHT once... Display reads:
Press the joystick DOWN once... Display reads:
Press the Joystick RIGHT once... Display reads:
Press the Joystick DOWN once... Display reads:
Press the Joystick RIGHT once... Display reads:
Press the joystick UP or DOWN to select Display reads:
{The display shows percentage of full CCW. i.e. 100.0 = full CCW.
50.0 = 50% CCW, 0.0 = Full CW. -0.1 = Fail in position (no move)}
After selection is displayed, press the joystick IN...
Display reads:
Press the joystick LEFT three times... Display reads:
Press the joystick UP twice... Display reads:
Press the joystick RIGHT once... DOWN twice,
then RIGHT once, the display will now show %
of CCW position (0.0 = Fully CW)
SET Process
in and out
INput Fault
done
SET Process
00 to 100
Fault Level
Fault Position
-0 .1
-0 .1 to 100 . 0
realtime
U
realtime
U
(Assumes actuator is powered up, running and is at the default display, showing position).
Notice: Any changes, settings or new calibration points are lost if a factory “Reset” is performed
on the controller. Contact the factory for details.
Controller: Change Loss of Signal Response Setting
