Promation Engineering P2 Series - Controller: Initial Startup

FM15_P28 HV PN7 (-TS) Ver I_052217
Page 8 P2/3 HV-PN7 Series
Press the joystick LEFT twice... Display reads:
Press the joystick DOWN twice... Display reads:
Press the joystick RIGHT once... Display reads:
Press the joystick RIGHT again... Display reads:
Press the joystick UP or DOWN
to toggle the display to available
selections...
When the correct INPUT signal is
displayed, press the joystick IN... Display reads:
Press the joystick LEFT twice... Display reads:
Press the joystick UP twice... Display reads:
Press the joystick RIGHT once... DOWN twice, then RIGHT once,
the display will now show % of CCW position (0.0 = CLOSED)
process in and out
4-20
(mA) (default)
0-10 (vdc)
1-5 (vdc)
2-10 (vdc)
done
SET process signals
00 to 100
SET process signals
realtime
U
realtime
U
Follow these instructions to change the input/output signal range or type:
(Assumes actuator is powered up, running and is at the default display showing position).
Power Up (baseline of normal functionality):
1. Apply power to the actuator and wait 20
seconds for the controller to power up, self-
test, and stabilize.
2. Immediately on power up the fault status light
will begin blinking at a rate of once per second
throughout operation
3. The 4 digit display will begin sequencing
through the self-test messaging.
4. Because there are only 4 display characters
the text will scroll or crawl across the display.
5. At this point the actuator is functioning properly.
6. Note: Autocalibrating AFTER any
controller modi cations wipes out those
modi cations and the controller starts
from it’s new zero point.
4 digit display reads: How the display behaves Notes
example display
Power off
Initial power on display
test of all led elements
Software version
(in this example:
Version 1.15)
Actuator - Voltage
(in this example:
P2 Actuator - 120 volt)
Rotation display
showing 0.0% CCW
(Blank display before
power up)
(Static display for about 1
second)
(Text ‘crawls’ left to right.
Displays twice.)
(Text ‘crawls’ left to right.
Displays twice.)
(Static display, stays on.)
%%%%
8.8.8.8
UEr 1.15
P2-120
%%0.0
These instructions illustrate the initial power up sequence for power up, initial data displays, and position display so the user
has a baseline for proper startup sequencing.
(Assumes actuator is properly mounted and wired as directed elsewhere in this manual).
Controller: Initial Startup
Controller: Change INput/OUTput signal type
