13.2 Firmware Upgrade using USB
If necessary, your controller can have the firmware upgraded. Firmware is a set of instructions which tell the
controller CPU how to operate.
1- Obtain the hex file from Prominent and insert thumb drive with the new file into the USB port located behind
the Communication panel. See section 13 Capturing Data.
2- Press F2, UPDATE
3- The display shows the current hex file in use.
If NEWPGM is not a choice,
there are no compatible hex files on the USB drive.
the Aegis. If OLDPGM is not a choice,
there are no other backup hex files in the Aegis memory.
Choose New or Old to see a list of hex files.
4- Press F2 to scroll through the list of hex files. Press F1, Load to install the new
hex file.
5-
Remove the USB drive when prompted.
NOTE: OLDER FIRMWARE VERSIONS USE STEP 6.
6- The firmware is copied to the controller. When
complete Aegis will notify you to remove the USB
drive.
7- After you remove the drive, the controller will erase
the existing firmware and install the new one.
8- Once the new firmware is installed, the controller
will restart.
13.2.1 USB Save or Load the Program
A program is a list of instructions that the user can edit. Set-points, calibrations, names of I/O are all saved in the
program.
13.2.1.1 Saving to the USB
1- To save a copy of your current program onto a USB drive, insert a USB into the USB port located behind
the Communication panel. See section 13 Capturing Data.
2- Press F3 Config
3- If you have not previously saved a program on this USB you can only F1 SAVE
a copy to the USB.
USB drive active
Offline, All STOP
LOG UPDATE CONFIG
Hardware startup
..
.
Program file
AP16101399.hex
0.02% Complete
.
OK. Ready to program
Remove USB drive
100.00% Complete
Program file
OK. Ready to program
Remove USB drive
