To Next PageTo Next PageWhat to do if my ProMinent Voice Recorder says “!SD card full. Please replace!!“?
If your ProMinent Voice Recorder displays the message “!SD card full. Please replace!!“, it means the SD card is full. To resolve this, copy all data from the SD card to your PC and then erase the data on the SD card.
What to do if my ProMinent Voice Recorder says “! Unformatted SD card!!“?
If your ProMinent Voice Recorder displays the message “! Unformatted SD card!!“, it means the SD card is not formatted as FAT 16 or FAT 32. To fix this, format the SD card as FAT 16 or FAT 32. Be aware that all data on the SD card will be erased during formatting!
What to do if my ProMinent Voice Recorder says “!SD card write-protected!!“?
If your ProMinent Voice Recorder displays the message “!SD card write-protected!!“, it means the small switch on the side of the SD card is set to LOCK. To solve this, move the switch on the side of the SD card away from LOCK.
Why after changing the SD card, the traces of ProMinent Voice Recorder do not show the values immediately after 24:00 h?
If, after changing the SD card, the traces do not show the values immediately after 24:00 h, it is because no reset was performed before changing the SD card. Perform a reset by pressing F4 CONFIG, then F2 OPTION, and then F3 RESET in sequence.
What to do if my ProMinent Voice Recorder says “!Please insert SD card!!“?
If your ProMinent Voice Recorder displays the message “!Please insert SD card!!“, it means the recorder is activated but no SD card is fitted. To solve this, fit an SD card into the recorder.
General| Enclosure Protection | IP65 |
|---|---|
| Operating Temperature | 0 °C to +50 °C |
| Protection Class | II |
| Display | LCD |
| Input Signals | 4-20 mA, 0-10 V, digital inputs |
| Output Signals | 4-20 mA, relay outputs |
| Control Functions | PID control |
| Communication | Modbus |
| Power Supply | 100-240 V AC |
| Storage Temperature | -20 to 70 °C |
