ProMinent DULCOMARIN II - Function MAP

1 Function MAP
With the standard modules M, A, and P it is possible to activate the
following additional functions:
n Water level (4) with topping up (5)
n Sensor cap (3) with/without paddle switch (2)
n Automatic backwashing (1)
n Heating control (7)
n Gutter cleaning function (6)
A1103
1.
2.
3.
4.
5.
6.
7.
Fig. 1: Function extension with M, A and P module
The following software versions (from and including) must be
installed so that these functions can be activated:
n DXCa 3021
n M-Module 3010
n A-Module 3010
n P-Module 3000
Function extension with M, A and P
module
Function MAP
5
