ProMinent EXtronic EXBb - Control Inputs and Signal Types; Intrinsically Safe vs. Non-Intrinsically Safe Inputs

1
1
2
3
2
3
a)
b)
1 EXtronic
2 Inductive consumer
3 Varistor
1. Provide own contacts, supply voltage via contactor relay or
relay.
2. With the 100 V to 230 V versions, connect Varistor (U
N
= 275
V) or RC member (0.22 µF / 220 Ω) in parallel.
The connection terminal (23) for the potential equalisation line is
located on the housing next to the mains connection (12).
Tab. 3: Contact, analogue and pause input not intrinsically safe
EXBbG Input (+) Black (1)
Input (-) Black (2)
EXBbM Input (+) blue
Input (-) black
Tab. 4: Contact, analogue and pause input intrinsically safe [i,a]
(sheath colour: blue)
EXBbG Input (+) Black (1)
Input (-) Black (2)
EXBbM Input (+) blue
Input (-) black
10
20
30
40
50
60
70
100
1
0
19
0
50
10
20
30
40
60
70
80
90
23
12
Control inputs
Installation, electrical
29
