ProMinent EXtronic EXBb - Dimensional Drawings; Pump Dimensions (NS, PS Versions)

15 Dimensional drawing
Dimensions in mm
PP=11,5
D
NP=13
C
E
B
Ø 5,8
226
141
306
A
149
*
10
20
30
40
50
60
70
100
1
0
19
0
50
10
20
30
40
60
70
80
90
125
144
G
F
31
32
93
F
81
Version ,,NS, PS“
Version ,,SB“
Type Material
version
A B C Ø D E Ø F G
1000, 1601,
1201, 0803
NP1 391 136 69 70 6x4 38 229
1002, 0308,
2502, 2505,
1006
NP3 391 136 61 85 8x5 50 237
1310, 0613 391 136 52 100 8x5 66 244
0814, 0417 391 136 52 100 12x9 66 244
0430 381 137 46 135 DN10 117 304
ProMinent EXtronic
®
EXBb
Dimensional drawing
55
