ProMinent EXtronic EXBb - Technical Data: Supply Circuit; Supply Circuit Electrical Parameters

* A cable length of 10 m is taken into account.
For detailed data and when using in areas at risk of explosion,
observe operating instructions and type examination certificate of
diaphragm rupture sensor.
14.5.2
Electrical data for supply current circuit
14.5.2.1 For "non-intrinsically safe" version
Rated voltage: 100, 115 ± 10 %
200, 230 ± 10 %
500 ± 10 %
VAC
VAC
VAC
Maximum current consumption I
eff
*: 1.5 A
Max. peak current during a stroke I
peak
: 8 A
Maximum power consumption P
wirk
*: 50 W
* obtained by averaging over several strokes at the maximum
stroke rate
14.5.2.2
For "intrinsically safe" version
Rated voltage: 100, 115 ± 10 %
200, 230 ± 10 %
500 +6% -10%
VAC
VAC
VAC
Maximum current consumption I
eff
*: 1.5 A
Max. peak current during a stroke I
peak
: 8 A
Maximum power consumption P
wirk
*: 50 W
* obtained by averaging over several strokes at the maximum
stroke rate
14.5.3
Electrical data, details
Tab. 15: Pump types 1000, 2501,1601, 1201, 0803, 1002, 0308
Mains connection (V) 100 115 200 230 500
Max. current con‐
sumption*** (A)
1.6 1.4 0.7 0.8 0.3
Effective power con‐
sumption
1
(A)
0.27 0.29 0.14 0.17 0.09
Mean power con‐
sumption (W)
16 16 16 16 16
Fuse item 65* value
(A)
1.0T 0.63T 0.4T 0.315T 0.319
Fuse item 66** value
(A)
0.16T 0.16T 0.16T 0.16T -
Technical data
52
