ProMinent EXtronic EXBb - Identity Code Structure; Decoding the Identity Code

1 Identity code
Product range ProMinent EXtronic
®
, Version b
EXBb Degree of protection
G Gas explosion protection
M Firedamp and gas explosion protection
Pump
type
bar l/h
refer to nameplate
Dosing head material
PP1 PP with bleed valve, O-ring: EPDM
PP4 PP without bleed valve/ HV, O-ring: EPDM
NP1 Acrylic with bleed valve, O-ring: FPM-A
NP3 Acrylic with bleed valve, O-ring: FPM-A
NS3 Acrylic self-bleeding, O-ring: FPM-A
PS3 PVC self-bleeding, O-ring: FPM-A
TT1 PTFE + 25% carbon, flat seal: PTFE
SS1 Stainless steel 1.4571 with clamp rings, flat seal: PTFE
SS2 Stainless steel 1.4571 with internal thread1/4” NPT, seal: PTFE
SB1 Stainless steel 1.4571 with internal thread, Rp 1/4 or 1/2
SSM As SS1, with diaphragm rupture sensor
SBM As SB1, with diaphragm rupture sensor
Valve spring
0 With valve spring
1 With 2 valve springs (1.4571), 0.1 bar
Electrical connection
A 230 V, 50/60 Hz, open end
B 115 V, 50/60 Hz, open end
C 200 V, 50/60 Hz, open end
D 100 V, 50/60 Hz, open end
E 500 V, 50/60 Hz, open end
Control type
0 Internal stroke rate setting
1 External contact control
2 Analogue control 0–20 mA
3 Analogue control 4–20 mA
4 External contact control [i,a]
5 Analogue control 0–20 mA [i,a]
6 Analogue control 4–20 mA [i,a]
7 Manual with potential-free ON / OFF
Identity code
5
