Pump type Stroke rate Connector size
outside dimen‐
sion x inside
diameter
Suction lift* Priming lift** Permissible pri‐
ming pressure,
suction side
EXBb Strokes/min mm m water column m water column bar
1002 120 8x5 5 1.0 3.0
0308 120 8x5 5 1.8 1.5
2502 120 8x5 5 1.0 8.0
2505 110 8x5 5 1.5 3.5
1006 120 8x5 5 1.3 3.5
1310 110 8x5 5 1.9 2.0
0613 120 8x5 5.5 1.9 2.0
0814 110 12x9 5 2.0 1.5
0417 120 12x9 4.5 2.0 1.5
0430 110 DN10 5 1.8 0.8
0260 110 DN15 1.5 1.5 0.8
* Suction lift: with filled suction line
** Priming lift: with an empty suction line
Tab. 8: Metering pumps for media of higher viscosity "HV"
Pump
type
Maximum pump capacity at maximum back
pressure
Maximum pump capacity rate at medium back
pressure
EXBb bar l/h psi gph Ml /
stroke
bar l/h psi gph Ml /
stroke
1002 10 2.30 145 0.607 0.31 5 2.7 72.5 0.713 0.38
1006 10 6.00 145 1.585 0.83 5 7.2 72.5 1.902 1.00
1310 10 10.50 145 2.773 1.59 6 11.9 87 3.143 1.80
0814 8 14.00 116 3.698 2.12 4 15.4 58 4.068 2.33
1 gal= 3.78 l
Pump type Stroke rate Connector size
outside dimen‐
sion x inside
diameter
Suction lift* Priming lift** Permissible pri‐
ming pressure,
suction side
EXBb Strokes/min mm m water column m water column bar
1002 120 DN10 1.0 - 3.0
1006 120 DN15 1.3 - 3.5
1310 110 DN15 1.9 - 2.0
0814 110 DN15 2.0 - 1.5
* Suction lift: with filled suction line
** Priming lift: with an empty suction line
