P_SI_0025_SW
1
5
4
5
6
2
3
Fig. 36: Liquid end Sigma/ 1 120 SST
Pos. Description Type 04084, 04120,
07042
1 Spring **
2 Ball *
3 Ball seat -
4 Diaphragm rupture sensor, visual 1033323
5 Valve 809404
6 Multi-layer diaphragm 1035828*
* The items listed are included in the spare parts kit. ** Special accessories (not included in the spare parts kit). Tech‐
nical changes reserved.
Liquid end Sigma/ 1 120 SST
Exploded drawings Sigma/ 1
81
