Rail ends aach to the outside of each post
3. Place the enclosure hardware onto the rails.
• At least two persons are required to safely lift the system.
• Lift the enclosure hardware itself. Do not lift the system by its brackets.
Placing the enclosure hardware onto the rack rails
13
Vess A6600 /A6800/A7600/A7800 Storage Appliance for Video Surveillance
Rail ends attach on the
outside of the front and rear
rack posts
Rails installed
and tightened
Brackets
3U 16-bay enclosure
hardware
