3.7. Operating
After setting the power switch to the position ‘I’, the carriage will turn on. If the
carriage is to control the torch, set the arc ignition switch to the position ‘I’.
With state shown on the main menu (Fig. 6) the current program
can be changed by simultaneously pressing and rotating the knob F2. Use the speed
adjustment knob to change the current welding speed. Right rotation increases the
speed by the step of 0.1, and left rotation decreases the speed by the same step.
Use the travel direction switch to select a direction of motion. The carriage will
start moving according to the chosen program parameters. The indication of the current
operating mode will show on the display during program execution. The carriage
speed can be adjusted during operation using the speed adjustment knob; however,
the new speed will not be saved if the current program changes in the meantime.
The carriage stops after reaching the total length and confirmation
message shows on the display. Then, set the travel direction switch to the position
‘O’ to go into the main menu. After the work is finished, turn off the power using the
power switch and unplug the carriage from the power source.
CAUTION! If the arc ignition switch is set to position ‘I’, the torch
will start welding immediately after selecting a travel direction.
