1. GENERAL INFORMATION
1.1. Application
The LIZARD is a welding carriage designed to produce continuous or intermittent butt
and fillet welds using MIG/MAG torches with the handle diameter of 16–22 mm (0.63–
0.87’’). The carriage is fixed by permanent magnets and can work in the following
welding positions: PA/1F/1G, PB/2F, PC/2G, PD/4F, and PE/4G.
Accessories allow, for instance, welding with oscillation, using torches with the
handle diameter larger than 22 mm, two torches simultaneously, guiding the carriage
along outside edges, lap joints and templates, walls low or with holes, and on ceilings,
pipes, and tanks.
1.2. Technical data
Voltage
1~ 115–230 V, 50–60 Hz
Power
25 W
Welding position (according to
EN ISO 6947 and AWS/ASME)
horizontal
PA / 1F / 1G
PB / 2F
PC / 2G
PD / 4F
PE / 4G
vertical
PF / 3F / 3G (with optional oscillator)
PG / 3F / 3G (with optional oscillator)
Minimum path curvature radius
1500 mm (5 ft)
Torch type
MIG/MAG
Torch diameter
16–22 mm (0.63–0.87’’)
Maximum torch reach
80 mm (3.15’’)
Maximum permitted cable weight
horizontal work
12 kg (27 lbs)
vertical work
8 kg (18 lbs)
Minimum workpiece thickness
5 mm (0.20’’)
Ground clearance
5 mm (0.20’’)
Horizontal pulling force
220 N
Vertical pulling force
150 N
Cross slide adjustment range
0–35 mm (0–1.38’’, up-down, left-right)
Guide arm adjustment range
0–75 mm (2.95’’)
Horizontal speed
0–120 cm/min (0–47.2 in/min)
Vertical speed
0–110 cm/min (0–43.3 in/min)
Noise level
Less than 70 dB
Weight
14 kg (31 lbs)
